# Install Ansible di CentOS 7
## Introduction [**Ansible**](https://www.ansible.com) adalah sebuah provisioning tool yang dikembangkan oleh [**RedHat**](https://www.redhat.com). Yang mana tool ini berfungsi untuk mencatat setiap proses deployment atau pun konfigurasi pada beberapa server secara bersamaan. Berikut ini adalah contoh skenario dari penggunaan tool Ansible, yang digunakan untuk otomasi proses instalasi dan konfigurasi LAMP (Linux Apache MariaDB PHP), serta CMS WordPress pada CentOS 7 dan untuk artikelnya dibahas terpisah [**disini**](https://blog.madfxr.my.id/documentation/category/devops/automation-installation-lamp-dan-cms-wordpress-dengan-menggunakan-ansible). ## Scenario * **123.45.67.87 (Master)**. * **123.45.67.21 (Node 1)**. * **123.45.67.31 (Node 2)**. * **123.45.67.41 (Node 3)**. ## Installation ### Menambahkan Repository EPEL Sebelum kita meng-install paket software Ansible pada **123.45.67.87 (Master)**, terlebih dahulu kita install repository paket software EPEL pada CentOS 7, berikut perintah yang digunakan: {% code overflow="wrap" lineNumbers="true" %} ```bash yum install epel-release -y ``` {% endcode %} ### System Update Setelah repository paket software EPEL telah ter-install, langkah selanjutnya kita lakukan pembaruan pada sistem, berikut perintah yang digunakan: {% code overflow="wrap" lineNumbers="true" %} ```bash yum update -y ``` {% endcode %} ### Install Paket Software Ansible Sebelum Ansible dapat digunakan di CentOS 7, terlebih dahulu kita harus meng-install paket software-nya, berikut perintah yang digunakan: {% code overflow="wrap" lineNumbers="true" %} ```bash yum install ansible -y ``` {% endcode %} ### Melihat Versi dari Ansible Untuk melihat versi dari Ansible yang telah ter-install, berikut perintah yang digunakan: {% code overflow="wrap" lineNumbers="true" %} ```bash ansible --version ``` {% endcode %} {% hint style="success" %} {% code title="Output" %} ```bash ansible 2.6.2 config file = /etc/ansible/ansible.cfg configured module search path = [u'/root/.ansible/plugins/modules', u'/usr/share/ansible/plugins/modules'] ansible python module location = /usr/lib/python2.7/site-packages/ansible executable location = /usr/bin/ansible python version = 2.7.5 (default, Jul 13 2018, 13:06:57) [GCC 4.8.5 20150623 (Red Hat 4.8.5-28)] ``` {% endcode %} {% endhint %} ### Melakukan Generate SSH Key Sebelum menjalankan Ansible untuk otomasi proses instalasi dan konfigurasi LAMP (Linux Apache MariaDB PHP), serta CMS WordPress pada CentOS 7. Terlebih dahulu kita harus melakukan generate SSH Key, hal ini dilakukan untuk menghasilkan Private Key dan Public Key yang nantinya akan digunakan sebagai autentikasi ketika terjadi komunikasi antar Master dengan Node, berikut perintah yang digunakan: {% code overflow="wrap" lineNumbers="true" %} ```bash ssh-keygen -t rsa -b 4096 ``` {% endcode %} {% hint style="success" %} {% code title="Output" %} ```bash Generating public/private rsa key pair. Enter file in which to save the key (/root/.ssh/id_rsa): Enter passphrase (empty for no passphrase): Enter same passphrase again: Your identification has been saved in /root/.ssh/id_rsa. Your public key has been saved in /root/.ssh/id_rsa.pub. The key fingerprint is: SHA256:NHEVLUATliGY19iuIYP1DkIB21QkE4wvY5PlWUeBdgs root@ansible.localhost The key's randomart image is: +---[RSA 4096]----+ | .+*=o==*O*oo | | .++oE ==+.. . | | .*.* *oo . | | * * +.+.. | | . + . =So | | o | | | | | | | +----[SHA256]-----+ ``` {% endcode %} {% endhint %} {% hint style="info" %} ```markdown -t = Spesifikasi tipe autentikasi untuk file Private Key dan Public Key dari SSH yang dibuat rsa = Tipe autentikasi keamanan komunikasi data yang digunakan oleh SSH -b = Spesifikasi nilai atau angka untuk ukuran file Private Key dan Public Key dari SSH yang dibuat 4096 = Ukuran file Private Key dan Public Key dari SSH yakni 4096 bit ``` {% endhint %} ### Autentikasi Akses SSH ke Setiap Node Proses selanjutnya yakni melakukan autentikasi login pada setiap Node, hal ini dilakukan agar Master yang terpasang oleh Ansible dapat menjalankan perintah secara otomatis pada setiap Node tanpa memerlukan autentikasi password lagi, berikut perintah yang digunakan: {% code overflow="wrap" lineNumbers="true" %} ```bash ssh-copy-id root@123.45.67.21 ssh-copy-id root@123.45.67.31 ssh-copy-id root@123.45.67.41 ``` {% endcode %} {% hint style="success" %} {% code title="123.45.67.21 (Node 1)" %} ```bash /usr/bin/ssh-copy-id: INFO: Source of key(s) to be installed: "/root/.ssh/id_rsa.pub" The authenticity of host '123.45.67.21 (123.45.67.21)' can't be established. ECDSA key fingerprint is SHA256:8ZhrtOBj9Ei+y+gTQbqg0p1t4YwVHw+I0VB9qhONNjA. ECDSA key fingerprint is MD5:93:be:a2:b2:31:ac:fb:89:32:d3:79:35:b4:7b:9a:74. Are you sure you want to continue connecting (yes/no)? yes /usr/bin/ssh-copy-id: INFO: attempting to log in with the new key(s), to filter out any that are already installed /usr/bin/ssh-copy-id: INFO: 1 key(s) remain to be installed -- if you are prompted now it is to install the new keys root@123.45.67.21's password: Number of key(s) added: 1 Now try logging into the machine, with: "ssh 'root@123.45.67.21'" and check to make sure that only the key(s) you wanted were added. ``` {% endcode %} {% endhint %} {% hint style="success" %} {% code title="123.45.67.31 (Node 2)" %} ```bash /usr/bin/ssh-copy-id: INFO: Source of key(s) to be installed: "/root/.ssh/id_rsa.pub" The authenticity of host '123.45.67.31 (123.45.67.31)' can't be established. ECDSA key fingerprint is SHA256:5wLAxUbZ5Nt5/98jAaGlwfUrEkX3wknCo9ndSwkoW3U. ECDSA key fingerprint is MD5:48:c3:d5:3e:10:11:62:94:88:85:05:dd:d5:31:a6:1c. Are you sure you want to continue connecting (yes/no)? yes /usr/bin/ssh-copy-id: INFO: attempting to log in with the new key(s), to filter out any that are already installed /usr/bin/ssh-copy-id: INFO: 1 key(s) remain to be installed -- if you are prompted now it is to install the new keys root@123.45.67.31's password: Number of key(s) added: 1 Now try logging into the machine, with: "ssh 'root@123.45.67.31'" and check to make sure that only the key(s) you wanted were added. ``` {% endcode %} {% endhint %} {% hint style="success" %} {% code title="123.45.67.41 (Node 3)" %} ```bash /usr/bin/ssh-copy-id: INFO: Source of key(s) to be installed: "/root/.ssh/id_rsa.pub" The authenticity of host '123.45.67.41 (123.45.67.41)' can't be established. ECDSA key fingerprint is SHA256:PfPAuId7qvbvSjvBjcgcQ1ggYIANqHWXpIndH0E/wfo. ECDSA key fingerprint is MD5:e2:be:d5:98:c3:77:56:c8:24:b5:c1:e8:cd:a1:94:93. Are you sure you want to continue connecting (yes/no)? yes /usr/bin/ssh-copy-id: INFO: attempting to log in with the new key(s), to filter out any that are already installed /usr/bin/ssh-copy-id: INFO: 1 key(s) remain to be installed -- if you are prompted now it is to install the new keys root@123.45.67.41's password: Number of key(s) added: 1 Now try logging into the machine, with: "ssh 'root@123.45.67.41'" and check to make sure that only the key(s) you wanted were added. ``` {% endcode %} {% endhint %} ### Menambahkan List Host untuk Setiap Node Melakukan konfigurasi pada file hosts dari Ansible, hal ini dilakukan agar Master dapat mengenali IP Address dari setiap Node dan dapat berkomunikasi satu sama lain, berikut perintah yang digunakan: {% code overflow="wrap" lineNumbers="true" %} ```bash vi /etc/ansible/hosts ``` {% endcode %} {% hint style="warning" %} {% code title="/etc/ansible/hosts" %} ```markdown [ansiblehost] 123.45.67.21 123.45.67.31 123.45.67.41 ``` {% endcode %} {% endhint %} Untuk menyimpan konfigurasi file hosts tekan tombol **Esc**, kemudian tekan kombinasi huruf **`:wq`**. ## Testing ### Verifikasi Host Untuk melakukan pengecekan koneksi pada setiap Node dari Master, berikut perintah yang digunakan: {% code overflow="wrap" lineNumbers="true" %} ```bash ansible -m ping ansiblehost ``` {% endcode %} {% hint style="success" %} {% code title="Output" %} ```bash 123.45.67.21 | SUCCESS => { "changed": false, "ping": "pong" } 123.45.67.31 | SUCCESS => { "changed": false, "ping": "pong" } 123.45.67.41 | SUCCESS => { "changed": false, "ping": "pong" } ``` {% endcode %} {% endhint %} {% hint style="info" %} ```markdown -m = Opsi yang digunakan untuk menjalankan modul dari Ansible ping = Nama modul yang digunakan untuk melakukan pengecekan koneksi ansiblehost = Nama grup host dari yang digunakan untuk setiap Node ``` {% endhint %} Demikian sedikit pengetahuan dan pengalaman yang dapat saya bagikan, semoga apa yang telah saya sampaikan dapat bermanfaat bagi kita semua. --- # Agent Instructions: Querying This Documentation If you need additional information that is not directly available in this page, you can query the documentation dynamically by asking a question. Perform an HTTP GET request on the current page URL with the `ask` query parameter: ``` GET https://blog.madfxr.my.id/documentation/categories/devops/install-ansible-di-centos-7.md?ask= ``` The question should be specific, self-contained, and written in natural language. The response will contain a direct answer to the question and relevant excerpts and sources from the documentation. Use this mechanism when the answer is not explicitly present in the current page, you need clarification or additional context, or you want to retrieve related documentation sections.
